The Electrical Cross Arms from Jinmai Powerline are engineered to provide robust support for power lines and other electric equipment in pole line technology. These cross arms are an essential component in the construction and maintenance of transmission and distribution lines, ensuring the reliable and efficient delivery of power.
Versatile Applications: The cross arms are designed to cater to various utility needs, serving as power pole cross arms, utility pole cross arms, telephone pole cross arms, and light pole cross arms. They are used to support streetlight power, anchor conductors, and hold telephone lines, among other applications.
Durable Construction: Made from high-quality materials, the cross arms are built to withstand harsh weather conditions and the rigors of outdoor use. Jinmai Powerline is committed to using only the finest materials, avoiding recycled materials to ensure the longevity and performance of their cross arms.
Precision Manufacturing: The manufacturing process involves pressing the steel into shape, with all holes pressed in one operation to ensure a clean finish without burrs. This meticulous process ensures that the holes on the cross arms are accurately sized and that the matching holes for bolts are compatible, allowing for seamless assembly with other pole line hardware.
Easy Installation: The cross arms are designed to connect easily with utility poles using double arming bolts, pigtail bolts, or U bolts. Cross arm braces are also available to provide additional support and prevent the lines from sagging.
Corrosion Resistance: The cross arms undergo a hot dip galvanization process, which gives them a protective coating against rust and corrosion. This finishing step enhances their durability and ensures they remain functional for an extended period.
Customizable Specifications: Jinmai Powerline offers customization options for the cross arms, allowing customers to specify the material type, shape, design, hole configurations, bolt and nut types, and dimensions according to their specific requirements.
Material Selection: The first step in the manufacturing process is selecting the appropriate material. Jinmai Powerline prioritizes the use of premium quality steel for its strength and durability. The company avoids recycled materials to ensure that each cross arm can endure the harshest of conditions and last for a long time.
Design and Specification: Once the material is selected, the design process begins. Engineers and technicians work together to create detailed blueprints based on the customer's specifications. These blueprints include the dimensions, hole placements, and other critical details that will guide the manufacturing process.
Cutting and Shaping: The steel material is then cut to size using advanced cutting machinery. This step is crucial for ensuring accuracy and minimizing waste. After cutting, the steel is shaped into the desired cross arm design using presses and other forming equipment.
Hole Drilling: With the cross arm shape set, precise holes are drilled according to the design specifications. These holes are essential for the attachment of insulators, conductors, and other pole line hardware. Jinmai Powerline uses automated machinery to ensure the accuracy and consistency of the hole placements.
Galvanization: To protect the cross arms from corrosion and extend their lifespan, they are dipped in molten zinc. This hot dip galvanization process creates a protective coating that is resistant to rust and other forms of degradation. The result is a cross arm with enhanced durability and reliability.
Quality Control: Throughout the manufacturing process, quality control checks are performed to ensure that each cross arm meets Jinmai Powerline's high standards. This includes inspections for dimensional accuracy, hole placement, and the integrity of the galvanized coating.
Assembly and Packaging: Once the cross arms pass all quality checks, they are assembled with any additional components, such as bolts and braces, as per the customer's order. The finished cross arms are then carefully packaged to protect them during transportation.
Shipping and Delivery: Finally, the packaged cross arms are shipped to the customer's specified location. Jinmai Powerline ensures timely delivery to support the customer's project schedules and commitments.
1. Material Composition:
Primary Material: High-quality steel (specifically chosen for its strength and durability)
Optional Material: Composite materials for specific applications requiring lighter weight or additional resistance properties
Material Treatment: Hot dip galvanized coating for corrosion resistance and extended service life
2. Dimensions and Tolerances:
Standard Lengths: Range from 3 meters to 15 meters, depending on application requirements
Top Face Width: Varies according to the specific model, typically from 30 mm to 200 mm
Side Face Depth: Varies from 30 mm to 150 mm, depending on load-bearing requirements
Overall Length: Precise measurements based on customer specifications
Tolerances: Held to industry standards, ensuring a perfect fit with other pole line hardware
3. Hole Configurations:
Number of Holes: Customizable based on the utility needs, typically ranging from 2 to 12 holes
Hole Diameter: Varies from 10 mm to 30 mm to accommodate different bolt sizes
Hole Spacing: Evenly distributed along the cross arm, with precise center-to-center measurements
Hole Edge Distance: Adequate to prevent interference with adjacent components
4. Load Bearing Capacity:
Maximum Load: Varies based on the cross arm design and material, with options for light, medium, and heavy-duty applications
Weight Capacity: Specified in accordance with the expected load, ensuring safety and reliability
5. Bolt and Nut Specifications:
Bolt Types: Pigtail bolts, U-bolts, and double arming bolts, all hot dip galvanized for corrosion resistance
Bolt Diameter: Matches the hole diameter, ensuring a secure and stable connection
Nut Types: Compatible with the bolt types, providing a secure fastening mechanism
6. Finishing:
Galvanization Thickness: Adheres to international standards for corrosion protection, ensuring a minimum of 65 micrometers of zinc coating
Surface Roughness: Smooth to prevent damage to the insulators and other components
7. Testing and Certifications:
Load Testing: Each cross arm undergoes rigorous load testing to ensure it meets the specified strength requirements
Corrosion Testing: Accelerated aging tests to verify the effectiveness of the galvanization process
Compliance: Meets or exceeds national and international standards for pole line hardware
8. Packaging and Shipping:
Protective Packaging: Designed to prevent damage during transportation, ensuring the cross arms arrive in pristine condition
Shipping Options: Flexible shipping methods to meet the customer's timelines and logistical needs
Jinmai Powerline's electrical cross arms are manufactured with precision and care, ensuring that each unit meets the highest technical standards. These specifications are tailored to meet the diverse needs of power transmission and distribution networks, providing reliable and long-lasting support for electrical infrastructure. By choosing Jinmai Powerline, customers can trust that they are receiving electrical cross arms that are engineered for excellence and built to last.
