Jinmai Powerline is a dedicated manufacturer and supplier of high-quality electrical stay rods. These rods are integral components of pole-line hardware, used to connect ground anchors with stay wires to ensure the stability of power tower structures and poles. Jinmai Powerline's stay rods undergo a break load test before each shipment and are hot-dip galvanized according to ISO 1461 standards to ensure durability and corrosion resistance.
Material and Manufacturing: Primarily made of steel, the rods go through a series of processes including precision casting, rolling, forging, turning, milling, drilling, and galvanizing to ensure product strength and longevity.
Diverse Types: Stay rods are categorized into Bow Type and Tubular Type, including various forms such as stay bows, stay plates, eye rods, and turnbuckle rods, to accommodate different installation requirements and environmental conditions.
Wide Application: In the electric power sector, stay rods are used to stabilize tower structures and power poles; in pole-line technology, different forms of stay rods are utilized in power lines, distribution lines, and telecommunication lines.
Technical Specifications: The dimensions, weight, diameter, and length of the stay rods are customized based on specific customer requirements to meet the demands of various operating conditions.
Installation and Maintenance: The installation of stay rods should be performed by professionals to ensure correctness and safety. Jinmai Powerline provides detailed installation manuals to guide users on how to properly install and maintain the stay rods.
Raw Material Selection: The foundation of a high-quality stay rod lies in the choice of raw materials. Jinmai Powerline meticulously selects premium steel for its strength and durability. This material is chosen for its ability to withstand harsh weather conditions and the rigors of continuous use in electrical and telecommunication infrastructure.
Melting and Forging: The steel is first melted in high-temperature furnaces, often exceeding 1200 degrees Celsius, to achieve a molten state. This molten steel is then forged into the preliminary shape of the stay rod, utilizing advanced forging techniques to ensure uniformity and structural integrity.
Precision Casting: For more intricate designs, precision casting is employed. This process involves pouring the molten metal into a mold, which has been designed according to the specific requirements of the stay rod. The result is a detailed and accurate shape that serves as the basis for the final product.
Rolling and Shaping: Once the stay rod has been forged or cast, it undergoes rolling processes to achieve the desired dimensions. This step may involve several passes through rolling mills, which gradually reduce the thickness and shape the rod to its final form.
Machining: After the initial shaping, the stay rods are subjected to various machining processes. These may include turning, milling, drilling, and other precision operations to create threads, holes, or other features necessary for the rod's functionality and compatibility with other pole-line hardware.
Galvanization: To protect the stay rods from corrosion, they are hot-dip galvanized. This process involves coating the steel with a layer of zinc by submerging it in a bath of molten zinc. This not only enhances the rod's resistance to the elements but also provides a durable and aesthetically pleasing finish.
Quality Control: Throughout the manufacturing process, Jinmai Powerline employs rigorous quality control measures. Each stay rod is inspected for defects, dimensional accuracy, and adherence to the specified tensile strength and load-bearing requirements. This ensures that every stay rod meets the high standards set by Jinmai Powerline and the ISO 1461 standard.
Final Inspection and Packaging: Before being packaged and shipped, each stay rod undergoes a final inspection to verify its readiness for installation. This includes checking for any signs of damage during the manufacturing process and ensuring that each rod is correctly galvanized.
Material Composition: High-grade steel, chosen for its exceptional tensile strength and durability.Alloy steel and carbon steel are also used for specific applications requiring enhanced properties.Hot-dip galvanization is applied to provide a thick, durable zinc coating that protects against rust and corrosion.Some components may undergo electrogalvanization for an additional layer of protection.
Strength and Load-Bearing: The stay rods are designed to withstand high tensile forces, with specific strengths ranging from 40,000 to 120,000 psi (pounds per square inch), depending on the model and application.Each stay rod is rated for a specific load capacity, ensuring that it can support the weight and pressure of the structures it is intended for.
Dimensional Specifications:Available in various diameters to suit different installation requirements, typically ranging from 5/8 inch to 3/4 inch.Custom lengths are produced based on project specifications, with standard lengths accommodating most common applications.The threaded sections of the stay rods are precisely machined to ensure compatibility with other hardware components.
Quality Compliance:Jinmai Powerline's stay rods adhere to ISO 1461 standards for quality and corrosion protection.Each stay rod undergoes a series of tests, including break load tests, to verify compliance with the specified quality and performance standards.
Installation Considerations:Stay rods are typically installed at a 45-degree angle to the horizon for optimal support and tension distribution.The recommended depth of burial varies based on the size and load-bearing capacity of the stay rod.
Packaging and Shipping:Stay rods are securely packaged to prevent damage during transit, with protective measures against moisture and corrosion.Jinmai Powerline ensures timely delivery of orders, with the capability to ship bulk quantities for large-scale projects.
The manufacturing process of Jinmai Powerline's stay rods is a blend of traditional forging and modern machining techniques, combined with a focus on quality and corrosion protection. This results in stay rods that are not only reliable and durable but also built to last in the challenging environments where they are installed.
If you require a customized Guy Clamp, Jinmai Powerline's skilled workers and knowledgeable engineers can provide a solution from design to delivery in a short period.
If you are interested in our Guy Clamp or have any questions, please feel free to contact us.
