Stay Rods are an indispensable support component in the construction of power transmission, communication towers and optical cable networks, and are designed to fix and stabilize overhead lines. The stay rods produced by Handan Jinmai Fastener Manufacturing Co., Ltd. are made of high-strength steel and are hot-dip galvanized on the surface. They have excellent corrosion resistance and mechanical strength and are suitable for extreme weather conditions and high-load scenarios. The products are widely used in power transmission and distribution lines, substations, communication base stations, railway contact networks and other fields, providing safe and reliable anchoring support for infrastructure.
1. High-quality materials
Q235B/Q345B high-strength carbon steel or alloy steel is used to ensure tensile strength ≥375MPa, meeting stringent load-bearing requirements.
2. Precision structural design
The rod body thread adopts roll forming technology, combined with standardized connectors, to achieve fast installation and high-precision matching.
3. Long-term anti-corrosion
The surface is hot-dip galvanized (zinc layer thickness ≥85μm) or electroplated galvanized + passivation process, passed ISO 1461 standard salt spray test, and is suitable for humid, coastal and other corrosive environments.
4. Customized service
Supports non-standard size customization, provides M12-M48 multiple diameter specifications, and a length range of 1-6 meters to meet the needs of different engineering scenarios.
5. Safety certification
It complies with international standards such as GB/T 700 and ASTM A36, and has passed the fatigue test of a third-party organization to ensure long-term stability.
1. Raw material screening
Select high-quality steel billets, and use a spectrometer to test the chemical composition to ensure that the ratio of carbon, silicon, manganese and other elements meets the standards.
2. Precision forging
The rod body is formed by die forging, and the thread is processed by CNC machine tools, with an accuracy of ISO 6g tolerance.
3. Heat treatment and strengthening
The hardness of the material is improved (HRC 22-30) through quenching + tempering process, internal stress is eliminated, and the deformation resistance is enhanced.
4. Surface treatment
The coating is completed by a fully automatic hot-dip galvanizing line, supplemented by passivation and sealing, to achieve 360° anti-corrosion protection without dead ends.
5. Strict quality inspection
Magnetic particle inspection, tensile test and coating thickness detection are carried out piece by piece, and the qualified products are laser marked with traceability information.
Material: Q235B/Q345B carbon steel (optional stainless steel 304/316L)
Tensile strength: ≥375MPa (Q235B), ≥470MPa (Q345B)
Diameter range: Φ12mm-Φ48mm (support non-standard customization)
Standard length: 1m/2m/3m/4m/6m (customizable within ±0.5m)
Surface treatment: hot-dip galvanizing (average zinc layer ≥85μm) or electro-galvanizing + yellow passivation
Applicable temperature: -40℃ to +120℃
Implementation standards: GB/T 700, ASTM A36, ISO 1461
Conclusion：
As the core product of Handan Jinmai Fastener Manufacturing Co., Ltd., Stay Rods embodies 20 years of experience in the research and development of power hardware and advanced manufacturing technology. We use the full-process automated production line, CNAS certified laboratory and ERP quality traceability system as the cornerstone to ensure the excellent quality of each product from raw materials to finished products. Relying on global project service experience, Jinmai products have been exported to more than 30 countries and are widely used in landmark projects such as Southeast Asian power grid upgrades and Middle East photovoltaic power stations.
Choose Handan Jinmai, you will get:
✅ Professional team: One-to-one solution optimization by engineers
✅ Fast delivery: Regular products are shipped within 7 days, urgent orders are expedited within 48 hours
✅ Worry-free after-sales: Provide 10-year warranty commitment and lifetime technical support
Contact us now to get customized solutions and let Jinmai become your most reliable partner for global projects!
