Cable Puller are essential tools for efficiently laying high-voltage and optical cables in power construction projects. They are specifically designed for cable pulling under complex working conditions. Leveraging 20 years of experience in power hardware manufacturing, Handan Jinmai Fastener Manufacturing Co., Ltd. offers a full line of customizable traction equipment suitable for transmission lines, substations, and optical cable projects. These products utilize a modular design to accommodate varying wire diameters (25-500mm²) and tension requirements, significantly reducing the risk of damage during construction and improving project efficiency by over 30%.
1. Superior Load Capacity and Durability
The main structure is constructed of high-strength alloy steel, precision-forged, with a maximum load capacity of 8 tons, meeting the requirements of 500kV ultra-high voltage (UHV) projects.
Triple surface protection: hot-dip galvanizing, epoxy coating, and passivation treatment. Passed ISO9227 salt spray testing, with a corrosion resistance lifespan of ≥15 years.
2. Intelligent Anti-Damage Design
Adaptive rubber clamping module dynamically adjusts the clamping force (adjustable from 0.5 to 3.5 kN) to prevent cable insulation damage.
Universally swivel guide wheel design reduces lateral friction during cornering by 90%.
3. Ergonomic Optimization
The foldable frame (unfolded dimensions: 1.2 x 0.8 m, storage volume reduced by 60%) and equipped with a hydraulic power assist system enable single-person operation.
Dual-mode drive: supports electric (220V/380V) and manual emergency switching.
Process: Technical Implementation, Quality Control Standards
Material Forming: CNC Precision Forging + Copper-Aluminum Friction Welding, Ultrasonic Flaw Detection
Surface Treatment: Automated Hot-Dip Galvanizing Line (Zinc Layer ≥ 85μm), ISO 1461 Adhesion Testing
Assembly and Testing: Laser Positioning Assembly + Dynamic Load Test Bench, IEC 61300 Vibration Testing
Applicable Cables: Ø30-80mm, Ø50-120mm, Ø80-200mm; Maximum Pulling Force: 5T, 8T, 12T;
Drive Mode: Electric-Hydraulic, Dual-Mode Drive, Diesel-Hydraulic; Linear Speed: 3-15m/min, 2-12m/min, 1.5-8m/min;
Weight: 85kg, 140kg, 220kg; Customization Options: ✔ Voltage Compatibility, ✔ Explosion-Proof Configuration, ✔ Remote Monitoring
- Customization Supported: Special wire diameter adaptation, bird-repellent integration, and other value-added services are available.
Handan Jinmai Fastener Manufacturing Co., Ltd., an innovator in the field of power construction equipment, deeply integrates precision manufacturing with engineering practice. Our cable pulling machines have been successfully applied in State Grid transformation, high-speed rail electrification projects, and overseas energy projects. Our 72-hour rapid customization response capabilities have earned us global recognition.
Get your customized solution now: ✉️ Customization Inquiry Email: [email protected]📱 Technical Communication Hotline: WhatsApp/WeChat +86 13831001495🌐 Support Services: We provide a full-process service from 3D drawing confirmation to prototype production to on-site guidance.
"Simplifying Complex Construction"—Jinmai continues to empower power construction.
